1PCS & 110V / 220V / 380V 1.5KW HUANYANG / HY Inverter VFD

• Inverter Type: 110v 13A

• Input Voltage:110V(+/-15%)

• Input Frequency:48-63 Hz

• Output Voltage:110VAC

• Output Frequency:0-400 Hz

• Input Phase:1 or 3 phase

• Output Phase:3 phase

• Warranty:1 year from the date you purchased

• Inverter Type: 220v 7A

• Input Voltage:220V(+/-15%)

• Input Frequency:48-63 Hz

• Output Voltage:220VAC

• Output Frequency:0-400 Hz

• Input Phase:1 or 3 phase

• Output Phase:3 phase

• Warranty:1 year from the date you purchased

• Inverter Type: 380v 4A

• Input Voltage:380V(+/-15%)

• Input Frequency:48-63 Hz

• Output Voltage:380VAC

• Output Frequency:0-400 Hz

• Input Phase:3 phase

• Output Phase:3 phase

• Warranty:1 year from the date you purchased

DO NOT set up the inverter by yourself if you don't know how to,  or it will make both the spindle and inverter burn easily.
Please contact us, we have manuals, videos and pictures to help you.

Original HY (Huangyang) brand inverter, stable using.
Control Mode is SPWM,it is very easy to use and convenient Protection functions are very strong, Fin over-heat protection, Overload protection, Fuse protection, Restart after instant stop,stall protection. Powful function.

·PID control;advanced calculous PID closed-loop arithmetic,quick responding speed and high suitability;

·Easy PLC function can realize 16 legs of speed and inverter control function;

·RS485 communication port,adopting standard international MODBUS main circuit control;

·With extremely strong anti-jamming capability:

·Low output ratting torque 0.5HZ-150%,low speed running ability:

·Carrier adjustable by 16KHZ,completely soundless working environment;

·Broad voltage working area,normal running in 304V-456V:

·Auto voltage regulation(AVR)technique,for ensuring the inverter load capability:

·Various control technique by both synchronization and non-synchronization,dynamically realize fast starting without changing brakes;

·With perfect error protection and short circuit starting protection capability;

·Dead-time compensation and auto torque slip compensation function,can realize 180%high orque output at low frequency 0.25Hz；

·Unique EMC design,can minimize inverter's pollution to power；

·Overall reinforcement layer to suit all kinds of harsh enviroment；
