SURPASS audio Official Store
Smart Home Audio 4 Channel Wireless Bluetooth In Wall Amplifier Touch Screen,Flush-mounted Radio,USB TF Card Power for Speaker
Limited Time Offer
Choice
Trending
Now:
$101.67
Was:
$166.67
-39% Now
Up to 4 x $25 with no interest
Deliver to
Ship from Local Warehouse
Smart Home Audio 4 Channel Wireless Bluetooth In Wall Amplifier Touch Screen,Flush-mounted Radio,USB TF Card Power for Speaker
Free Shipping
Delivery byMonday, September 29, Order within
Shipped By:
Fast Delivery
- $5.00 coupon code if delayed
- Refund if package lost
- Refund if items damaged
- Refund if no delivery in 30 days
SKU:
AE12000028128450712
Brand: SURPASS audio Official Store
Security & Privacy
FREE Return
Shop sustainably
Smart Home Audio 4 Channel Wireless Bluetooth In Wall Amplifier Touch Screen,Flush-mounted Radio,USB TF Card Power for Speaker SPECIFICATIONS: …
Related Products
Description
● Power: AC220V(50HZ) allow 110V-250V
● Main screen size: 4 inch HD screen
● Output Power: RMS 4x20W
● Output Impedance: 4-8Ω
● T.H.D.: 0.03%
● Frequency Response: 20Hz-20KHz
● Audio S/N: 98dB
● Expand TF card memory: 32G
● USB: 0TG USB function, 32G can be read
● Size: 86*86*11mm
1 x mounted box
1 x remote control
1 x bracket and screw
● Languages only support English and Chinese, please check before your purchase.
● For this device, speaker cable and power cable is not included.
① Don't connect exceed RMS 20W speaker and it should be 8ohm. If your speaker exceed 8ohm RMS 20Watts, the amplifier will be burnt out as your own risk.
② Use exceed 150-core pure copper speaker cable to connect speakers. Click to get:
200 core https://www.aliexpress.com/item/4000938426917.html
100 core https://www.aliexpress.com/item/1005001859469936.html
③ Use power cable cord as the amplifier request (two cord).
● If there is any questions about the product or you need our technical support, please contact us.
● Video Playlist: https://youtube.com/playlist?list=PLo58qiwgS__woxhjGV9BWnr_wl9zyXfqI
Connection Guide https://youtu.be/G7mWynbcC3Q
1 How to connect antenna with the wall amplifier https://youtu.be/YRYsBwAUYhw
2 How to use FM function 2 https://youtu.be/GHbV33zwiwY
3 How to connect with phone via Bluetooth https://youtu.be/0QuwVKs4dHQ
4 How the wall amplifier controls and be controlled by the phone https://youtu.be/cEZJtBWBu8I
Smart Home Audio 4 Channel Wireless Bluetooth In Wall Amplifier Touch Screen,Flush-mounted Radio,USB TF Card Power for Speaker
SPECIFICATIONS:
Smart Home Audio 4 Channel Bluetooth Wall Amplifier Specifications:● Power: AC220V(50HZ) allow 110V-250V
● Main screen size: 4 inch HD screen
● Output Power: RMS 4x20W
● Output Impedance: 4-8Ω
● T.H.D.: 0.03%
● Frequency Response: 20Hz-20KHz
● Audio S/N: 98dB
● Expand TF card memory: 32G
● USB: 0TG USB function, 32G can be read
● Size: 86*86*11mm
PACKAGE INCLUDED:
1 x smart touch screen on-wall amplifier1 x mounted box
1 x remote control
1 x bracket and screw
NOTES:
● In some country, the FM Radio Function may not works well, because the signal may be affected due to different frequencies in different countries and regions.● Languages only support English and Chinese, please check before your purchase.
● For this device, speaker cable and power cable is not included.
① Don't connect exceed RMS 20W speaker and it should be 8ohm. If your speaker exceed 8ohm RMS 20Watts, the amplifier will be burnt out as your own risk.
② Use exceed 150-core pure copper speaker cable to connect speakers. Click to get:
200 core https://www.aliexpress.com/item/4000938426917.html
100 core https://www.aliexpress.com/item/1005001859469936.html
③ Use power cable cord as the amplifier request (two cord).
● If there is any questions about the product or you need our technical support, please contact us.
● Video Playlist: https://youtube.com/playlist?list=PLo58qiwgS__woxhjGV9BWnr_wl9zyXfqI
Connection Guide https://youtu.be/G7mWynbcC3Q
1 How to connect antenna with the wall amplifier https://youtu.be/YRYsBwAUYhw
2 How to use FM function 2 https://youtu.be/GHbV33zwiwY
3 How to connect with phone via Bluetooth https://youtu.be/0QuwVKs4dHQ
4 How the wall amplifier controls and be controlled by the phone https://youtu.be/cEZJtBWBu8I
*** Please noted that the speaker in the pictures just show that the amplifier can connect up to 4 speakers, but the speakers are not including in the package
Smart Home Audio 4 Channel Wireless Bluetooth In Wall Amplifier Instructions:
1. Speaker: Speaker wire (200 cores). RVH2X100,RVH2X200 connect to SPK R+ SPK R-.
2. Speaker: Speaker wire (200 cores). RVH2X100,RVH2X200 connect to SPK R+ SPK R-.
3. Audio input wire: Audio wire (three core shielded wire: commonly known as microphone wire). RVVP2X0.5, RVVP2X0.75 connect to AUX L+AUX R+GND.
4. Audio output wire: Audio wire (three core shielded wire: commonly known as microphone wire). RVVP2X0.5, RVVP2X0.75 connect to OUT R +OUT L+GND. Can be connected to other amplifiers.
5. FM: Radio antenna
6. Trigger the doorbell: Connect to GND+DB to trigger the doorbell.
7. Power supply terminal: Connect AC110V-240V power supply.
How to install Smart Home Audio 4 Channel Wireless Bluetooth In Wall Amplifier?
Package includes:
Notes: the link is not including the speakers, if you need the speakers together, please chcek:
https://www.aliexpress.com/item/1005001499921529.html?spm=5261.ProductManageOnline.0.0.e5fd4edf8riO9O
